Model:Furukawa HB15G Hydraulic breaker
Part Name:Hydraulic breaker seal kit,Hydraulic hammer seal kit
Tool Ø:120MM
Part Number:HB15G-2-SK
Material:TPU+HNBR+PTFE
Packaging Details:bag or box +carton
Certification: IOS 9001
Delivery Time: 2-5days upon payments confirmed
Position:Furukawa Hydraulic Breaker Systerm
Brand:TOPARTS, OEM or as Required
Payment Terms: TT/Paypal/WEST UNION
Supply Ability:50
MOQ:1set
Parts list
| 符号 Item |
部品番号 Part No. |
部品 Part Name |
個数 Q’ty |
| HB15G-2-SK | シール キット SEAL KIT |
1S | |
| 1 | HB15G-10307 | Uバックキン U-Packing |
1 |
| 2 | HB15G-10308 | バッファ リング Buffer Ring |
1 |
| 3 | HB15G-10310 | ダウト シール Dust Seal |
1 |
| 4 | HB15G-10212 | スライド パッキン Slide Packing |
2 |
| 5 | HB15G-10213 | オーリング O-Ring |
2 |
| 6 | HB15G-10214 | シール リング Seal Ring |
1 |
| 7 | HB15G-10215 | バックアップ リング Back-up Ring |
1 |
| 8 | 161011—-00145 | オーリング O-Ring |
2 |
| 9 | 262031-00145 | バックアップ リング Back-up Ring |
3 |
| 10 | 001200-10020 | ノック ビン Knock Pin |
2 |
| 111 | 60011—-00026 | オーリング O-Ring |
4 |
| 12 | HB15G-10121 | Bush | 2 |
| 13 | 161011-00012 | オーリング O-Ring |
2 |
| 142 | 62021—-00012 | バックアップ リング Back-up Ring |
2 |
| 151 | 60011—-00011 | オーリング O-Ring |
4 |
| 16 | HB10G-10120 | Plug | 1 |
| 17 | 160011-00024 | オーリング O-Ring |
2 |
| 18 | HB20G-13208 | フェイス シール Face Seal |
1 |
| 19 | 161025-00025 | オーリング 0-Ring |
2 |
| 2016 | 1025—-00035 | オーリング O-Ring |
2 |
| 2116 | 1025—-00040 | オーリング O-Ring |
3 |
| 22 | 161025-00055 | オーリング O-Ring |
1 |
| 23 | 262032-00055 | バックアップ リング Back-up Ring |
1 |
| 24 | 001300-20112 | ラバー ブラグ Rubber Plug |
3 |
| 25 | 160011-00018 | オーリング O-Ring |
2 |
| 26 | 262022-00040 | バックアップ リング Back-up Ring |
2 |
| 27 | 161011—-00024 | O-Ring | 2 |
| 28 | 160011-00006 | オーリング 0-Ring |
1 |
| 29 | 160021—-00180 | オーリング 0-Ring |
1 |
| 30 | HB20G-70219 | フェイス シール Face Seal |
1 |
| 31 | 160011—-00005 | オーリング O-Ring |
1 |
| 32 | 160011—-00014 | オーリング O-Ring |
2 |
Exploded view
Product Description
High-Performance HB15G2SK Hydraulic Breaker Seal Kit for Furukawa HB15G
Keep your Furukawa HB15G hydraulic breaker operating at peak efficiency with the HB15G2SK professional service repair kit. Designed for one of the industry’s most reliable mid-range hammers, this kit is essential for preventing hydraulic oil leaks and maintaining consistent impact energy during demolition, trenching, and quarrying tasks.
At Toparts, we manufacture our Furukawa-compatible kits using high-grade materials specifically selected to withstand the intense friction and heat generated within the HB series’ high-frequency striking system.
Product Highlights:
100% OEM Compatibility: Precision-engineered as a direct replacement for the Furukawa HB15G2SK kit, ensuring a perfect fit for HB15G hydraulic hammers.
Industrial-Grade Materials: Features premium Polyurethane (PU) for exceptional abrasion resistance and NBR for superior heat stability and oil seal integrity.
Restore Breaking Power: Effectively seals the hydraulic chambers to prevent internal bypass, ensuring your piston delivers maximum force with every stroke.
Engineered for Tough Jobs: Built to resist the extreme vibrations and thermal fluctuations common in heavy-duty construction environments.
Complete Overhaul Set: Includes all necessary rod seals, buffer seals, dust wipers, and specialized O-rings required for a professional and secure repair.
Technical Specifications:
Brand Compatibility: Furukawa (FKK)
Hammer Model: HB15G
Part Number (P/N): HB15G2SK
Component Type: Hydraulic Breaker / Rock Hammer Service Kit
Material: Premium PU, NBR, PTFE + Bronze
Excavator Class: 12.0 – 18.0 Ton
Condition: 100% Brand New Aftermarket
